SRP5030TA-1R2M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.2UH 6.5A 16 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP5030TA-1R2M Datasheet
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$0.704
- 2,000$0.612
- 4,000$0.5985
Quote It
Technical Details
- Series:SRP5030TA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Carbonyl Powder
- Inductance:1.2 µH
- Tolerance:±20%
- Current Rating (Amps):6.5 A
- Current - Saturation (Isat):11A
- Shielding:Shielded
- DC Resistance (DCR):16mOhm Max
- Q @ Freq:10 @ 100kHz
- Frequency - Self Resonant:50MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.224" L x 0.205" W (5.70mm x 5.20mm)
- Height - Seated (Max):0.118" (3.00mm)
